Bottom price Rammer Compactor - SINOMACH 20-28ton LLC228_226_223_220 Trash compacting machine Refuse Compactors trucks – China Construction Detail:

Model LLC220 LLC223 LLC226 LLC228
Total weight kg 20000 23000 26000 28000
Front wheel axle load kg 9500 11000 12500 13500
Rear wheel axle load kg 10500 12000 13500 14500
Long mm 7355 7355 8150 8150
Width mm 3000 3000 3800 3800
High mm 3600 3600 3650 3650
Wheelbase mm 3350 3350 3500 3500
Ground clearance mm 435 435 490 490
Width of pressure roller(front/rear) mm 1040/835 1040/835 1195/970 1195/970
Diameter of pressure roller(front/rear) mm 1500/1500 1500/1500 1620/1620 1620/1620
Number of teeth of pressing wheel(front/rear) 50/40 50/40 50/40 50/40
Engine manufacturer SHANGCHAI SHANGCHAI SHANGCHAI SHANGCHAI
Engine model SC8DK200G3 SC8DK200G3 SC9DK260G3 SC9DK260G3
Engine power kw 147 147 192 192
Engine speed r/min 2200 2200 2200 2200
1 Forward speed km/h 0-4.2 0-4.2 0-4.41 0-4.41
2 Forward speed km/h 0-10 0-10 0-7.1 0-7.1
3 Forward speed 0-10.87 0-10.87
Reverse speed 1 gear km/h 0-5.8 0-5.8 0-4.41 0-4.41
Reverse speed 2 gear 0-7.1 0-7.1
Maximum climbing ability % 100 100 100 100
Dozer height mm 1650 1650 1880 1880
Dozer width mm 3000 3000 3800 3800
Dozer lifting height mm 1000 1000 1200 1200
Dozer depth mm 150 150 200 200
Steering angle ±° 40 40 40 40
Lateral swing angle ±° 15 15 15 15
Turning radius(outside front wheel) mm 6250 6250 7200 7200
Fuel tank L 450 450 500 500
Hydraulic tank L 236 236 236 236
Drive method Hydraulic transmission,power shift,all-wheel drive
Service brake Pneumatic push oil,four-wheel caliper disc brake
Parking/emergency braking Mechanical,expanding shoe brake
Steering method Hydraulic,central articulated,swingable
