China Supplier Front End Loaders - LIUGONG 2Ton CLG820C Wheel Loader – China Construction
China Supplier Front End Loaders - LIUGONG 2Ton CLG820C Wheel Loader – China Construction Detail:
Turbo air filter removes over 90% of dust and impurities, reducing engine wear and fuel consumption extending engine service life and improving engine efficiency.
Radiator fan is directly engine driven and provides strong efficient cooling.
38 degree angle of articulation for working in tight spaces.
Low fuel consumption engine that doesn’t sacrifice any power.
Very low cycle time of 8.6 second, great for efficient for smooth strong gear changes.
Meets EU stage IIIA/EPA tier 3 emission requirements.
Power cut-off function prevents damage to drive components.
Double sealed O-rings brand new in Hydraulic system.
Stress analysis tested to strengthen weak points.
| Model | 820C Wheel Loader | |
| Bucker performance | 1.0 m³ | |
| Operating weight | 6,400 kg | |
| Engine | emission regulation | Tier 2 / Stage II |
| make | YT4B4-24 | |
| gross power | 65 kW (87 hp) @ 2,400 rpm | |
| net power | 60 kW (80 hp) @ 2,400 rpm | |
| peak torque | 305 N·m @ 1,600 rpm | |
| displacement | 9.7L | |
| number of cylinders | 4 | |
| aspiration | natural | |
| Transmission | Transmission Type | counter shaft-type power shift |
| Torque Converter | 3 element-single stage,single phase | |
| Maximum Travl Speed.fwd | 25km/h | |
| Maximum Travl Speed.rev | 25km/h | |
| number of Speed.fwd | 2 | |
| number of Speed.rev | 2 | |
| Brakes | Service Breake Type | caliper dry disc |
| Service Breake Actuation | hydraulic | |
| Parking Brake Type | shoe/drum | |
| Parking Brake Actuation | mechanical | |
| Hydraulic system | Main pump Type | gear |
| Main Relief Pressure | 18Mpa | |
| Raise | 5.2 s | |
| Dump Time | 1.2s | |
| Float Down Time | 3s | |
| Fastest Total Cycel Time | 9.40 s | |
| Loader arm performance | Tipping load-straight | 4,997 kg |
| Tipping load-Full Turn | 4,487 kg | |
| Bucket Breakout Force | 56 kN | |
| Maximum Dump Angle at Full Height | 45±1 ° | |
| Dump Clearance at full height discharge | 2,856 mm | |
| Dump reach at full height discharge | 769 mm | |
| Maximum hinge pin height | 3,608 mm | |
| Maximum Digging depth,Bucket level | 23 mm | |
| Bucket rollback at ground level | 45° | |
| Bucket rollback at carry | 49° | |
| Bucket rollback at maximum height | 61° | |
| Dimensions | Length with bucket down | 6,125 mm |
| width over tires | 1904mm | |
| wheelbase | 2,310 mm | |
| wheel Tread | 1520mm | |
| Ground Clearance | 285mm | |
| Turn Angle,Either Side | 38° | |
| Rear Angle of Departure | 28.5° | |
| Turning Radius,Outside of Tire | 4,347 mm | |
| Turning Radius,Center of Tire | 4,119 mm | |
| Turning Radius,Bucket Carry | 4,979 mm | |
| Service Capacities | FuelTank | 95L |
| Engine Oil | 16L | |
| Cooling System | 21L | |
| Hydraulic Reservoir | 78L | |
| Transmission and Torque Converter | 20L | |
| Axles,each | 12 L | |
Product detail pictures:
