[Copy] CNCMC 1.3 Ton CT15 High Quality CNCMC Chinese MINI Excavator

Introduction:

This machine is suitable for rock loading, clearing and excavation of frozen soil in coal mines, metal mines, non-metallic mines, shafts, inclined shafts and roadway excavation. The machine has the following characteristics: Compared with the traditional artificial clearing, the machine can greatly improve the working efficiency while saving the labor cost, improve the working environment, and the operator is working under the protection of the cab, which is beneficial for safe production. Compared with the traditional diesel-powered mini excavator, the electric hydraulic system has the characteristics of energy saving, low noise, no exhaust pollution and high efficiency, and it is more suitable for underground use. The machine is compact in structure, small in size and small dispensing parts, which is convenient for vertical downhole use. With the smallest swing structure, when the body turned on the car, the tail will not exceed the width of the car, so it is more suitable for working in small space underground.


Product Detail

Product Tags

Video

Features

The machine is compact in structure, small in size and small dispensing parts, which is convenient for vertical downhole use. With the smallest swing structure, when the body turned on the car, the tail will not exceed the width of the car, so it is more suitable for working in small space underground.

1

Product parameter

Performance Parameters (CT-15 Pilot model)
Weight 1350kg Power 15kw
Bucket digging force 13.5kn Engine model koop 292
Gradeability 30° Bucket capacity 0.04m³
Dimension
Transport length 2450mm Walking speed 3.0km/h
Chassis width 980mm Track width 180mm
Total track length 1250mm Minimum ground clearance 380mm
Scope of work
Maximum digging depth 1800mm Maximum digging height 2500mm
Minimum radius of gyration 1550mm Maximum ground excavation radius 2400mm
Maximum unloading height 1850mm Hydraulic system Eaton
Transport size 2550*1100*2200mm

Product Image

主图6
主图7

Our Company

详情_01
详情_02
详情_03
详情_04
详情_05
详情_06
详情_07
