Factory best selling Flatbed Truck Crane - LIUGONG 55Ton Truck Crane 5 Sections Boom 45.6M Lifting Height TC600C5 Mobile Crane – China Construction Detail:

The largest crane operating range, and the most optimal lifting performance in the industry.



Five-section U-shaped boom of large cross section with maximum length reaches up to 45m and jib of the length of 16 m.



The 7.5m transverse outrigger span with a fixed counterweight of 3.3t makes its lifting performance 5-10% higher than that of the products of same class.



Imported ISLe series high pressure common rail large torque euro III engine of 340 horsepower is configured.



The combination of Fast 9-speed gearbox and double reduction axle features large speed ratio range, which meets the requirements of low gradeability speed and high traveling speed.



The max. traveling speed is 85km/h and max. gradeability is up to 46%.



Load sensitive valve compensation technology, with stable control.

Max. rated lifting capacity

55 t

Max. rated lifting torque of basic boom

2033 kN·m

Max. rated lifting torque of full extended

1192 kN·m

Max. lifting height of main boom

45.6 m

Max. lifting height of Jib

45.6+16.4 m

Overall net weight

43400 kg

Max. single rope speed

130 m/min

Time of telescoping boom

100 s

Time of elevating boom

45

Max. slewing speed

2.2 rpm

Max. travel speed

85 km/h

Gradeability

47%

Min. turning diameter

24 m

Dimensions (L x W x H)

13950x2800x3730 mm

Outrigger longitudinal span

5750 mm

Outrigger transverse span

Full:7500 / Half:5020 mm

Sections of boom

5

Length of main boom

45 m

Length of jib

16 m

Type

ISL9.5-340E51A

Engine Model

QSB6.7-C220

Rated power

251/164 kW

Max. rated torque

1500/949 N·m
