Factory directly supply Automatic Compactors - SINOMACH 20-28ton LLC228_226_223_220 Trash compacting machine Refuse Compactors trucks – China Construction
Factory directly supply Automatic Compactors - SINOMACH 20-28ton LLC228_226_223_220 Trash compacting machine Refuse Compactors trucks – China Construction Detail:
Model | LLC220 | LLC223 | LLC226 | LLC228 | |
Total weight | kg | 20000 | 23000 | 26000 | 28000 |
Front wheel axle load | kg | 9500 | 11000 | 12500 | 13500 |
Rear wheel axle load | kg | 10500 | 12000 | 13500 | 14500 |
Long | mm | 7355 | 7355 | 8150 | 8150 |
Width | mm | 3000 | 3000 | 3800 | 3800 |
High | mm | 3600 | 3600 | 3650 | 3650 |
Wheelbase | mm | 3350 | 3350 | 3500 | 3500 |
Ground clearance | mm | 435 | 435 | 490 | 490 |
Width of pressure roller(front/rear) | mm | 1040/835 | 1040/835 | 1195/970 | 1195/970 |
Diameter of pressure roller(front/rear) | mm | 1500/1500 | 1500/1500 | 1620/1620 | 1620/1620 |
Number of teeth of pressing wheel(front/rear) | 50/40 | 50/40 | 50/40 | 50/40 | |
Engine manufacturer | SHANGCHAI | SHANGCHAI | SHANGCHAI | SHANGCHAI | |
Engine model | SC8DK200G3 | SC8DK200G3 | SC9DK260G3 | SC9DK260G3 | |
Engine power | kw | 147 | 147 | 192 | 192 |
Engine speed | r/min | 2200 | 2200 | 2200 | 2200 |
1 Forward speed | km/h | 0-4.2 | 0-4.2 | 0-4.41 | 0-4.41 |
2 Forward speed | km/h | 0-10 | 0-10 | 0-7.1 | 0-7.1 |
3 Forward speed | 0-10.87 | 0-10.87 | |||
Reverse speed 1 gear | km/h | 0-5.8 | 0-5.8 | 0-4.41 | 0-4.41 |
Reverse speed 2 gear | 0-7.1 | 0-7.1 | |||
Maximum climbing ability | % | 100 | 100 | 100 | 100 |
Dozer height | mm | 1650 | 1650 | 1880 | 1880 |
Dozer width | mm | 3000 | 3000 | 3800 | 3800 |
Dozer lifting height | mm | 1000 | 1000 | 1200 | 1200 |
Dozer depth | mm | 150 | 150 | 200 | 200 |
Steering angle | ±° | 40 | 40 | 40 | 40 |
Lateral swing angle | ±° | 15 | 15 | 15 | 15 |
Turning radius(outside front wheel) | mm | 6250 | 6250 | 7200 | 7200 |
Fuel tank | L | 450 | 450 | 500 | 500 |
Hydraulic tank | L | 236 | 236 | 236 | 236 |
Drive method | Hydraulic transmission,power shift,all-wheel drive | ||||
Service brake | Pneumatic push oil,four-wheel caliper disc brake | ||||
Parking/emergency braking | Mechanical,expanding shoe brake | ||||
Steering method | Hydraulic,central articulated,swingable |
Product detail pictures:
Related Product Guide:
Just about every member from our large efficiency income crew values customers' wants and enterprise communication for Factory directly supply Automatic Compactors - SINOMACH 20-28ton LLC228_226_223_220 Trash compacting machine Refuse Compactors trucks – China Construction , The product will supply to all over the world, such as: Finland, Kenya, Salt Lake City, In order to meet the increasing requirement of customers both home and aboard, we will keep carrying forward the enterprise spirit of "Quality, Creativity, Efficiency and Credit" and strive to top the current trend and lead fashion. We warmly welcome you to visit our company and make cooperation.
