LIUGONG 2Ton CLG820C Wheel Loader
Hydraulic system easily checked after removing front cover.
Easy engine access, convenient placement of key parts and fluid refill points.
Power cut-off function prevents damage to drive components.
Double sealed O-rings brand new in Hydraulic system.
Stress analysis tested to strengthen weak points.



Model | 820C Wheel Loader | |
Bucker performance | 1.0 m³ | |
Operating weight | 6,400 kg | |
Engine | emission regulation | Tier 2 / Stage II |
make | YT4B4-24 | |
gross power | 65 kW (87 hp) @ 2,400 rpm | |
net power | 60 kW (80 hp) @ 2,400 rpm | |
peak torque | 305 N·m @ 1,600 rpm | |
displacement | 9.7L | |
number of cylinders | 4 | |
aspiration | natural | |
Transmission | Transmission Type | counter shaft-type power shift |
Torque Converter | 3 element-single stage,single phase | |
Maximum Travl Speed.fwd | 25km/h | |
Maximum Travl Speed.rev | 25km/h | |
number of Speed.fwd | 2 | |
number of Speed.rev | 2 | |
Brakes | Service Breake Type | caliper dry disc |
Service Breake Actuation | hydraulic | |
Parking Brake Type | shoe/drum | |
Parking Brake Actuation | mechanical | |
Hydraulic system | Main pump Type | gear |
Main Relief Pressure | 18Mpa | |
Raise | 5.2 s | |
Dump Time | 1.2s | |
Float Down Time | 3s | |
Fastest Total Cycel Time | 9.40 s | |
Loader arm performance | Tipping load-straight | 4,997 kg |
Tipping load-Full Turn | 4,487 kg | |
Bucket Breakout Force | 56 kN | |
Maximum Dump Angle at Full Height | 45±1 ° | |
Dump Clearance at full height discharge | 2,856 mm | |
Dump reach at full height discharge | 769 mm | |
Maximum hinge pin height | 3,608 mm | |
Maximum Digging depth,Bucket level | 23 mm | |
Bucket rollback at ground level | 45° | |
Bucket rollback at carry | 49° | |
Bucket rollback at maximum height | 61° | |
Dimensions | Length with bucket down | 6,125 mm |
width over tires | 1904mm | |
wheelbase | 2,310 mm | |
wheel Tread | 1520mm | |
Ground Clearance | 285mm | |
Turn Angle,Either Side | 38° | |
Rear Angle of Departure | 28.5° | |
Turning Radius,Outside of Tire | 4,347 mm | |
Turning Radius,Center of Tire | 4,119 mm | |
Turning Radius,Bucket Carry | 4,979 mm | |
Service Capacities | FuelTank | 95L |
Engine Oil | 16L | |
Cooling System | 21L | |
Hydraulic Reservoir | 78L | |
Transmission and Torque Converter | 20L | |
Axles,each | 12 L |
