Low MOQ for Digger Compactor Wheel - SINOMACH 20-28ton LLC228_226_223_220 Trash compacting machine Refuse Compactors trucks – China Construction
Low MOQ for Digger Compactor Wheel - SINOMACH 20-28ton LLC228_226_223_220 Trash compacting machine Refuse Compactors trucks – China Construction Detail:
Model | LLC220 | LLC223 | LLC226 | LLC228 | |
Total weight | kg | 20000 | 23000 | 26000 | 28000 |
Front wheel axle load | kg | 9500 | 11000 | 12500 | 13500 |
Rear wheel axle load | kg | 10500 | 12000 | 13500 | 14500 |
Long | mm | 7355 | 7355 | 8150 | 8150 |
Width | mm | 3000 | 3000 | 3800 | 3800 |
High | mm | 3600 | 3600 | 3650 | 3650 |
Wheelbase | mm | 3350 | 3350 | 3500 | 3500 |
Ground clearance | mm | 435 | 435 | 490 | 490 |
Width of pressure roller(front/rear) | mm | 1040/835 | 1040/835 | 1195/970 | 1195/970 |
Diameter of pressure roller(front/rear) | mm | 1500/1500 | 1500/1500 | 1620/1620 | 1620/1620 |
Number of teeth of pressing wheel(front/rear) | 50/40 | 50/40 | 50/40 | 50/40 | |
Engine manufacturer | SHANGCHAI | SHANGCHAI | SHANGCHAI | SHANGCHAI | |
Engine model | SC8DK200G3 | SC8DK200G3 | SC9DK260G3 | SC9DK260G3 | |
Engine power | kw | 147 | 147 | 192 | 192 |
Engine speed | r/min | 2200 | 2200 | 2200 | 2200 |
1 Forward speed | km/h | 0-4.2 | 0-4.2 | 0-4.41 | 0-4.41 |
2 Forward speed | km/h | 0-10 | 0-10 | 0-7.1 | 0-7.1 |
3 Forward speed | 0-10.87 | 0-10.87 | |||
Reverse speed 1 gear | km/h | 0-5.8 | 0-5.8 | 0-4.41 | 0-4.41 |
Reverse speed 2 gear | 0-7.1 | 0-7.1 | |||
Maximum climbing ability | % | 100 | 100 | 100 | 100 |
Dozer height | mm | 1650 | 1650 | 1880 | 1880 |
Dozer width | mm | 3000 | 3000 | 3800 | 3800 |
Dozer lifting height | mm | 1000 | 1000 | 1200 | 1200 |
Dozer depth | mm | 150 | 150 | 200 | 200 |
Steering angle | ±° | 40 | 40 | 40 | 40 |
Lateral swing angle | ±° | 15 | 15 | 15 | 15 |
Turning radius(outside front wheel) | mm | 6250 | 6250 | 7200 | 7200 |
Fuel tank | L | 450 | 450 | 500 | 500 |
Hydraulic tank | L | 236 | 236 | 236 | 236 |
Drive method | Hydraulic transmission,power shift,all-wheel drive | ||||
Service brake | Pneumatic push oil,four-wheel caliper disc brake | ||||
Parking/emergency braking | Mechanical,expanding shoe brake | ||||
Steering method | Hydraulic,central articulated,swingable |
