Shantui 24ton Bulldozer 240Hp Dh24-b2 With Rear Ripper
Control system
● The double-module (Function and safety) controller architecture verifies with each other to achieve higher safety and reliability.
● The malfunction self-diagnosis function is provided to accurately indicate the malfunction cause and orientation and shorten the downtime.
● The service software with distinct access hierarchy features high simpleness and practicability and easy learning and understanding
Driving/Riding Environment
The integral ergonomic hexahedral cab features large space, excellent vision, and good airtightness.
● The suspended single accelerator pedal features small volume, large foot space, and high operation comfort.
● The extensively adjustable seat and armrests provide the driver with the most comfortable operation posture.
● The standard canopy and the optional standard cab + heating and A/C system are provided. The cab adopts integrally sealed shock-absorbing system and sound-absorbing sponge to lower the driver’s parotic noise to 85dB and realize low vibration and noise.
● The intelligent display and control terminal with integrated instruments, cigarette lighter, USB charging port, radio, toolbox, sun shade, and fire extinguisher to provide more abundant personalized driving/riding experience and guarantee the comfortable and safe driving/riding environment.
● The safety passage system of the machine guarantees the driver’s safety
Working adaptability
● The machine adopts double-circuit electronically controlled hydrostatic drive system to ensure good load self-adaptability, loaded and in-situ steering capability, stepless speed regulation, and high flexibility and efficiency and realize outstanding construction performance in narrow sites.
● The undercarriage system features long ground length, high ground clearance, stable driving, and excellent trafficability. The standard traction frame and the optional three-shank ripper are provided.
● The standard LED working lamps of higher illumination intensity improve the illumination capability during nighttime operations to achieve higher safety and reliability
Easy maintenances
● The structural parts inherit the excellent quality of Shantui mature products.
● The electric harnesses adopt seamless corrugated pipes and deconcentrators for branching, featuring high protection grade.
● The core electric and hydraulic parts adopt imported products, featuring stable and reliable quality and extremely high reliability.
● The modular structure design of the machine features easy disassembling and assembling, simple repairs, low failure rate, and easy maintenances


Parameter name | DH24-B2 XL | DH24-B2 LGP |
Performance parameters | ||
Operating weight (Kg) | 23850 | 26450 |
Ground pressure (kPa) | 68.4 | 40.9 |
Engine | ||
Engine model | Weichai WD12G250E202 | Weichai WD12G250E202 |
Rated power/rated speed (kW/rpm) | 185/1900 | 185/1900 |
Overall dimensions | ||
Overall dimensions of machine (mm) | 6095*3640*3192 | 6255*4365*3228 |
Driving performance | ||
Forward speed (km/h) | 0-11 | 0-11 |
Reversing speed (km/h) | 0-11 | 0-11 |
Chassis System | ||
Center distance of track (mm) | ||
Width of track shoes (mm) | 560/610(Optional)/660(Optional) | 910 |
Ground length(mm) | 3050 | 3482 |
Tank capacity | ||
Fuel tank (L) | 390 | 390 |
Working device | ||
Blade type | Semi-U | Straight-tilt |
Digging depth (mm) | 540 | 550 |
Ripper type | 3 shank | - |
Ripping depth (mm) | 655 | - |
