XCMG 8ton XD82 Road Roller Compactor Machine

Introduction:

XD82 vibratory roller is suitable for the compaction of asphalt concrete surface layer, can also be used for the compaction of small and medium-sized foundations, sub-foundations and filling materials. It is an ideal compaction equipment for the maintenance of asphalt pavement in the municipal maintenance and high-speed management.


Product Detail

Product Tags

Video

Performance Characteristics

The steering wheel can adjust angle according to the need of the driver.

Control handle, display, etc. are arranged on the right side to broaden the front view. * Speed frequency management system guides the user to compaction operation.

Guiding the user to improve operation efficiency.

The vibration drum realizes the center of four-in-one combination.

Preventing the over-compaction and less-compaction.

Making the road surface more even.

Double-sealing technology.

Dual frequency dual amplitude vibration system.

Independent vibration of front and rear drum.

1
2

Specification

Parameter

Unit

XD82

Weight distribution

Working weight

kg

8500

Front wheel distribution weight (kg)

4250

Rear wheel distribution weight (kg)

4250

Compaction performance

Static linear load

N/cm

248/248

Nominal amplitude

mm

0.35/0.70

Vibration frequency

Hz

48/45

Exciting force (high frequency/low frequency)

kN

40/80

Vibration wheel size

mm

1150×1680

Maneuverability

Speed range

km/h

0~9.5

Theoretical gradeability

%

30

Minimum turning radius mm (in/out)



4100/5780

Swing angle

°

±8

Steering angle

°

±38

Engine

model



DEUTZ BF4M2012-10T3R

Type



Inline four-cylinder pressurized water-cooled

Rated power

kW

74.9

Rated speed

r/min

2300
